2017 year

Table 1600-1800 1/1000th degree X-axis:4000 Y-axis:2500 Z-axis:2000 W-axis:700 ATC-40FANUC-31iMB-axis scale attached Spindle through coolant

2010 year

3000/2000/1600/700RT 1600 x 1800Sub pallets 1800 x 2000APC 2 palletsATC 40Fanuc 31iALinear scale XYZBTSC 20 ba

2011 year

XYZW 2000/1500/1200/550RT 1400 x 1600(7,000kgs)Spindle speed Max. 3000 rpmFanuc 32iAATC 40T

2013 year

31i-MASpindle Dia. : 130mmTravel :XYZ – 3000/2000/1600 mmW – 700 mmRotary Table (1/1000 ͦ)Size : 1800 x 2000 mmMax. Load : 15000 KgSpindleSpeed : 2500 rpmTool type : BT50ATC : 40 toolsMachine Weight 4

2000 year

Control Fanuc 15MRotary Table 2000 x 2500 mmX - 6000 mmY - 3000 mmZ - 750 mmW - 900 mmSpindle dia. 150 mmSpindle speed 5~1500 rpm (3 steps)Spindle taper BBT 50Spindle motor 37/30 KwTool shank BT50ATC

2005 year

CONTROLLER TOSNUC 888, Table: 1000x1000Table Index: 0.0001mmTravel: 1500mm x 1200mm x 700mmSpindle travel : 400Dia: 110mmSpindle: BT50ATC: 54 stations

2013 year

XYZW 2500/2000/1500/600RT 1400 x 1800Spindle speed Max. 4000 rpmFanuc 31iAScale XYZBCTS 20 barATC 40

2011 year

XYZW 2000/1500/1200/550RT 1400 x 1600(7,000kgs)Spindle speed Max. 3000 rpmFanuc 32iAATC 40T

2006 year

XYZW -  3000 X 2300 X 1600 X 400 MM, SPINDLE -12 000, TABLE 2000X 2200MM , MAX LOAD ON TABLE : 15000 KG,fanuc 16i MB

2014 year

 X= 14.800 mm.Y= 6.000 mm.Z, Ram= 1.200 mm.W, Spindle= 1.000 mmCNC SIEMENS 840 D, 2 pcs of Auto. Microindexed head A- & C-axis, 360.000°, with Inside / Outside coolant and air.Touch prob

2010 year

HNK HB-130 year 20103000/2000/1300/700RT 1600 x 1800ATC 40Splash guardChip conveyor Fanuc 18iMB

2017 year

XYZW 3000/2300/1600/650RT 2000 x 2200Max. Loading capacity 25TSpindle speed Max. 4,000 rpmFanuc 31iB5ATC 40Linear scale (XYZB Heidenhain)Universal head (Manual index)Right angle headCTS 30 barTool pro

2008 year

DB130CX year 20083000/2000/1600/700RT 1800 x 2000Fanuc 18iMBATC 60CTS 20 ba

2004 year

3000/2000/1600/700RT 1800 x 2000Fanuc 16MATC90CTS 30bar

2009 year

X-axis 6,000mmY-axis 3,000mmZ-axis 800mmW-axis 700mmSpindle dia. Ø 150mmSpindle motor AC 45/55 kwSpindle speed Max. 2,000 rpmRam size 420 x 420mmCNC system Fanuc 18iMB3. Optional accessoriesOperator p

2003 year

X - 2500 MM, Y - 2000MM, Z - 1500MM, W- 700MM, B AXIS - 0.001 Controller Fanuc Series oi-MD, max load on table 10 tons.

2012 year

HNK HB-150Spindle quill Dia. 150mmROTARY TABLE 0.001mm70bar CTSTool Pre-setter Workpiece probe60 Tool ATC

2001 year

X 9000MM, Y 3000MM, Z 1100MM, QUILL DIAMETER 130MM, PALLET 1500X2000MM,  TOTAL NUMBER OF PALLET - 3NOS. CONTOLEER : FANUC 15M, SPINDLE SPEED : 4000 RPM, WEIGHT ON PALLET - 25TONS

2001 year

X/Y/Z/W -5000/3000/1000/1000MM, B - 9999.999 DEG, U AXIS - +/- 100MM FACING SLIDE LONGITUDINAL, V - 1500MM  Table longitudinal. tool holder : SK50, Spindle Dia -160mm, Table size : 1600x 2000mm -

2001 year

SIEMENS 840D CONTROLLER, XYZ - 2000/2400/3000MM , B AXIS +/- 9999.999 DEG, W- 600MM, U = +/= 100MM, SPINDLE POWER 45KW, SPINDLE RPM 3000, SPINDLE TAPER : SK50, FACING HEAD TYPE : 700

1990 year

Nomura HBM 110 , table size 1400x1600 , 1875 up & down axis 2000 front & back axis 1400 left & right axis 500 w axis Fanuc OM control Total 2 unit

2012 year

4000/2500/2000/700RT 1600 x 1800Fanuc 31iALinear scaleCTS 20 barSplash guardATC 40

2003 year

XYZ,- 2000/ 1500/1450MM, W AXIS - 500MM, TABLE SIZE :  1400X1600MM, SPINDLE DIA : 110MM, SPINDLE TAPER - BT50, CONTROLLER TOSNUC 888

2003 year

X AXIS - 3000MM, Y AXIS - 2300MM, Z AXIS - 1600, W AXIS 700MM, TABLE LOAD , 12 TON, TABLE : 2200X1800MM TABLE INDEX- 0.0001 DEG, SPINDLE DIA - 130MM (110: HIGH SPEED), SPINDLE TAPER:BT50, CONTROLLER&n

2002 year

X AXIS - 3000MM, Y AXIS - 2300MM, Z AXIS - 1600, W AXIS 700MM, TABLE LOAD , 12 TON, TABLE : 2200X1800MM TABLE INDEX- 0.0001 DEG, SPINDLE DIA - 130MM (110: HIGH SPEED), SPINDLE TAPER:BT50, CONTROLLER l

2008 year

DB-130CX year 20083000/2000/1600/700RT 1800 x 2000Fanuc 18iMBATC 40

2013 year

TOSNUC 999/CAT50/INDEXING 0.0001 DEGREE

2012 year

3000/2000-1600/700 RT 1800 x 2000 Fanuc 31iA No ATC

2008 year

XYZW 11,000/5,000/1,200/1,000 RT 2500 x 2500 Max. Loading capacity 40T Boring spindle 160mm Ram size 500 x 500 Floor plate 6000 x 5000 Spindle motor 100kw Siemens 840D 2 axis universal head

2018 year

2500/2000/1500/550 RT 1400 x 1800 Max. 4000 rpm Fanuc 31iB ATC 40

2012 year

2000/2000/1600/700 RT 1600 x 1800 Fanuc 31iA ATC 40 CTS 20 bar

2015 year

DOUBLE COLUMN CNC SPECIFICATIONS     Qty: 1 machines     MAKE     FPT Control    Siemens 840 YEAR    2015 Table dimensio

2012 year

DBC-130 year 2012 2000/2000/1600/700 RT 1600 x 1800 Fanuc 31iA ATC 40

2018 year

2500/2000/1500/550 RT 1400 x 1800 Max. 4000 rpm Fanuc 31iB ATC 40

2011 year

   4000/2500/2000/700 RT 1800 x 2000 ATC 40 Fanuc 31iA 90 deg. Angle head

1989 year

CNC TABLE BORING(TOSHIBA,BTD-11R16) 1. MAKER : TOSHIBA 2. MODEL : BTD-11R16 3. CNC : TOSNUC 777 4. Year 1989 5. OPTION : ㅡ.ROTARY TABLE : 1,600 X 1,800mm ㅡ.STROKE : 2,000×1,500×1,45

2010 year

  CONVENTIONAL BORING MACHINE Qty: 1 machines Model TPX6113/2 YEAR 2010 MAKE  SHENYANG MACHINE TOOL CO. LTD.

1993 year

CNC BORING MACHINE MAKETOSHIBAMODELBF 130AYEAR 1993CONTROLLER FANUC 15MW AXIS450MMX AXIS6000 MMY AXIS2500 MMZ AXIS450 MMSPINDLE SPEED5-800 RPMSPINDLE TAPERBT 50MAX LOAD ON TABLE20000kGT

2011 year

3000/2000/1600/700RT 1800 x 2000ATC 60CTS 20 barLinear scaleSplash guardFanuc 31i

2008 year

Hyundai Wia KBN-135 year 20083000/2000/1600/7001800 x 2000ATC 60CTS 20 barFanuc 16iMB

2010 year

3000/2000/1300/700RT 1600 x 1800ATC 40Splash guardChip conveyor Fanuc 18iMB

2012 year

XYZW4000/2500/2000/7001800 x 2000ATC 40XYZ linear scaleCTS 30 barFanuc 31iA, spindle rpm 2500

2008 year

XYZW 8000/4000/1000/1215Between columns 3550Table top to spindle center 2185Table size 3000 x 7800OSP-P200MATC 120Right angle head auto. Index 5 deg. AAC

2012 year

X/Y/Z/W4000/2500/2000/7001800 x 2000ATC 40XYZ linear scaleCTS 30 barFanuc 31iA

2012 year

X/Y/Z/W4000/2500/2000/7001800 x 2000ATC 40XYZ linear scaleCTS 30 barFanuc 31iA

2010 year

4000/2300/1600/700RT 1800 x 2000Fanuc 31iAATC 40CTS 20 barBT. 50 tooling

2010 year

XYZW 4000/2000/1600/700RT 1800 x 2000ATC 60BT50CTS 30 barFanuc 31iA

2008 year

X/Y/Z/W3000/2300/1600/700ROTARY TABLE 1600 x 1800ATC 40Linear scaleFanuc 18iMB

year

YEAR OF MFG 1978 AND RETROFIT 2020CONTROLLER FANUC 16-MBX / Y / Z  - AXIS - 2500MM / 2100MM/850MMW AXIS - 1000MMTABLE WORKING SURFACE - 1400 X 2700 MMTABLE LOAD 6000 KGATC 60 TOOLS BT50

2012 year

MAKEHYUNDAI-WIA , KOREAMODELKBN-135CYEAR 2012SPINDLE TAPERBT 50ATC 40CONTROLLER FANUC 31iX AXIS3000 MMY AXIS2000 MMZ 1 AXIS1600MMZ2 AXIS700 MMLOAD ON TABLE16000 KGROTARY TABEL SIZE

1998 year

MAKETOSHIBA, JAPANMODELSHIBAURU, BF 130BYEAR DECEMBER, 1988SPINDLE TAPERBT 50ATC 60CONTROLLER TOSNUC 888 CNC CONTROLX AXIS6000 MMY AXIS2500 MMZ 1 AXIS1000MMZ2 AXIS450 MMLOAD ON TABLE160

2009 year

HYUNDAICNC BORING MACHINEModelKBN135MFG DateFEB..2009X axis4000 mmY axis2500 mmZ axis1600 mmtable size1800x 2000mmControllerFanuc 16i-MBBoring bar Diameter135 mmTable indexing accuracy0.001ATC 40

2008 year

BORING & MILLING MACHINE  MAKETOSHIBA , JAPANMODELBTD 110.R16YEAR 2008SPINDLE TAPERBT 40ATC 40CONTROLLER TOSNUC 999W AXIS500MMY AXIS1500 MMX AXIS2000 MMZ AXIS1450MMROTARY

2014 year

BORING & MILLING MACHINE  MAKEHNK  , KOREAMODELHB 130YEAR 2014SPINDLE TAPERBT 50ATC 60CONTROLLER FANUC SERIES 31i-Model AW AXIS500MMY AXIS2300 MMX AXIS3000 MMZ AXIS16

2006 year

X axis travel (table longitudinal)Inch (mm)98.43 (2,500)Y axis travel (spindle head vertical)Inch (mm)78.74 (2,000)Z axis travel (column cross)Inch (mm)47.2 (1,200)W axis travel (boring spindle axial)

year

HorizontalHone Machine Maximum ExternalDiameter 10", Minimum PartLength 4 feet, Maximum PartLength 43 feet, RPM Range 65 -374,

1997 year

Spindle Taper ISO 50. Swivel Head. Pegard Rotary Table L3.5 x W2.4 x H1.1m (11 'T' Slots). Approx Floor Plate Dimension 10.7 x 7m.

1994 year

Control TOSNUCATC Table 1250 x1250mm

1998 year

HORIZONTAL BORING AND MILLING MACHINEMAKENOMURA, JAPANMODELHBA-110T-R3SPINDLE TAPERBT50YEAR MILLING SPINDLE DIAMETER215MMCONTROLLER Fanuc 16-MW AXIS500MMY AXIS25 - 1500 MMX AXIS2000 MMZ AXIS

2011 year

Travel XYZ; 6m x 2.5m x 3mATC 60 Tools, BT50Spindle speed 8000rpm

2020 year

X AXIS - 2500MM,Y AXIS - 2100 MMZ AXIS  850MMW AXIS  1000MMTABLE WORKING SURFACE : 1400X 2700MMTABLE LOADING CAPACITY - 6000 KGSPINDLE SPEED RANGE  12.5 TO 1250 RPMTOOL STORAGE CAPACITY

1993 year

Column travel X axis9000mmHead stock travel Y axis3000mmZ AXIS1100mmQuill Diameter130mmPallet 1500 x 2000mmSpindle taperBT50Year1993spindle speed 4000 rpmTotal number pallets3Max weight on p
