2000 year

OM Turn mill  Table 3500Max. Swing 4100Max. TH 3000Ram stroke 1800C axis 0.001Milling spindle speed 1200 rpmAC 60/75KWFanuc 18TATC Turning 14 potsMilling 30 pots

year

Kolomna 15/40TTable 4000Swing 4500Max. TH 2500Fanuc 0MDouble ram

year

table 2000mmswing 2450mmmax turning height  1800mmram stroke 1250mmspindle motor 45/55kwcross rail : 200x 6 stepsFanuc 15TATC 12T

2007 year

 Chuck size 1250 Fanuc 18iTB, Max turning dia 1600 Max swing 1600Max job height 1250

year

TABLE 1800MM, DOUBLE RAM, 45DEGREE TILT

year

TABLE 1200MM, 45DEGREE ANGULAR RAM TILT

2003 year

Table 1250Swing 1600Max. Turning height 1000Z stroke 900AC 37/45kwATC 12Fanuc 18T

2009 year

Table / Max swing5000/7000Maximum cutting height (Above table)3700Load on Table60000Saalbar up and down movement area1800Third par left and right diagonal flow30 DegLeft and right movement of the Lar

2009 year

Table 2500Swing 3500Max. Turning height 2000Ram stroke 1200Crossrail 250 x 4 stepsAC 45/55kwFanuc 18iTBATC 12TLinear scale X,Z axis(Heidenhain)Splash guardChip conveyor

year

table 2500

year

TABLE  5500 and swing 7000Turning height 2650controller: Sentrol II

year

Make OMModel Table dia. 5000 mm, TH 3000mmMax. swing 7000 mm2 Rams

2010 year

CHUCK 900MM, TURRET TYPE, MILLING FUNCTION, COOLANT TANK, CHIP CONVEYOR

2012 year

CHUCK SIZE 550M , TURRET TYPE ATC, COOLANT TANK,CHIP CONVEYOR

2014 year

CHUCK SIZE 1600MM, WITH 12 TOOLS ATC, WITH MILLING FUNCTION AND C AXIS, COOLANT TANK AND CHIP CONVEYOR

2005 year

FANUC 18I-TBTABLE 3,000MMMAX. SWING 4,000MMMAX. T/H 2,400MMRAM STROKE 1,250MMCROSSRAIL 1,800MM (200 X 9 STEP)ATC 12T

2011 year

Table 2000Swing 2650Max. Turning dia. 2500Max. Turning height 2100Z stroke 1000W stroke 1100Ram size 250 x 250Spindle motor AC 60/75kwSpindle speed Max. 240 rpmC axis indexing 0.001C axis speed 2 rpmM

year

OM Japan conventional VTLTable 5000Swing 7000TH 3700

2015 year

Table 1600Swing 2000Max. TH 1400Ram stroke 900Crossrail elevation 700Spindle speed Max. 280rpmSpindle motor AC 37/45kwMilling spindle motor AC 15/18.5kwMilling spindle speed Max. 3,000 rpmC-axis index

2008 year

CHUCK SIZE : 2000MMSWING 2500 MMTH - 2200MMMAX LOAD ON TABLE 15000 KGFANUC Oi TCMachine weight 36T

2014 year

Gear hobbing machine functionTable size : 3,740 mmMaximum Cutting Diameter : 5,500 mmGear max tooth width : 550 mmMax. Modul : 32Max. workpiece weight : 39,4 tonCutter RPM : 10~150 rpmColumn forward a

2007 year

Table   1250Swing  1600Height  600RAM 350MMLOAD ON TABLE 8000KG360RPMATC-12FANUC-18i-TB

2008 year

Table 1600Max. Swing 2000Max. TH 1600Z stroke 900Crossrail 250 x 3 stepsTable speed 250rpmTable load 10,000 kgsTable motor AC 37/45kwMilling spindle speed Max. 2000 rpmMilling spindle motor AC 15/18.5

2009 year

Table 2500Swing 3500Max. Turning height 2000Ram stroke 1200Crossrail 250 x 4 stepsAC 45/55kwFanuc 18iTBATC 12TLinear scale X,Z axis(Heidenhain)Splash guardChip conveyor

2007 year

TABLE 860MM, BT 50. 12 TOOLS, FANUC -0i-TC

2012 year

chuck size : 1000mm ,Max turning height - 900mm, Z axis Ram stroke - 800mm, ATC magazine- 12 nos., Tool shank - BT50

1992 year

-Main spindle BT 50ATC 60 X 750Y 1100 Z 1200、Table size 800、Max job size 1100、Max job height 1200、Max job weight 1250 kg、Fanuc 15 M

2012 year

X 1350MMZ AXIS TRAVEL 900MMCHUCK DIAMETER 1600MMSWING 2000MMMAX TURNING HEIGHT 1250MMMAX LOAD ON TABLE 8000KGSPINDLE TAPER BT50ATC 16 TOOL

2010 year

TABLE 4500MMSWING 5000 MMSPEED 1-60RPMRAM SIZE 400X400MMLOAD ON TABLE 50000KGISO TAPER BT50Z AXIS 2000MMW AXIS - 25000MMMACHINE WEIGHT 160000 KG

2014 year

Table 5000Swing 8500Max. T/H 5,000Ram 2,500Max. Load 60TFanuc 31iARAA, EA, GAAOperator platform (elevator)Linear scale

2001 year

Table 2500Swing 3000Turning height 2000Z stroke 1200Fanuc 18TATC 12

2006 year

YOUJI YV2000ATC+CYear 2006Table 2000Swing 2500TH Max. 1573mmRam 1200mmCrossrail 800mmAC 60/75KwTable speed Max. 200 rpmC axis 3 rpmMilling spindle speed Max. 2400 rpmATC 60CTS90 deg. Angle headFanuc 1

2011 year

Table 2000Swing 2500Turning height 1800Z stroke 1000Crossrail 250 x 3 stepsAC 45/55kwTable speed 200 rpmMilling spindle AC 15/18.5kwMilling spindle speed 1500 rpmC-axis 0.001 deg. Fanuc 31iA** Op

2011 year

table 2000Swing 2500Turning height 1800Z stroke 1000Crossrail 250 x 3 stepsAC 45/55kwTable speed 200 rpmMilling spindle AC 15/18.5kwMilling spindle speed 1500 rpmC-axis 0.001 deg. Fanuc 31iA** Op

2000 year

X 15M

2019 year

LESS RUNNING HOURS

2001 year

Youji 1600 CNC VTLMax, swing 2000, table 1600Z travel 900, X travel 2310, cross beam movement 800mm16 Tool ATCRam sizes 220x220Spindle motor max 26/37kwFanuc 18T

2008 year

Chuck size : 2000mm, swing 2500mmX axis 3200mmZ axis 1200mmRam sizes 250x250mmc/w tool pre-setter, 16 tools ATC, OD/ID holdersMax workpiece height 2000(from table surface to OD tool holder base distan

2014 year

Chuck size 3000mm, swing 3600mmX axis 4400mmZ axis 1500 travelc/w vertical and horizontal workpiece probe. Tool pre-setter. Table Dia 3000mm. Extra workpiece height (estimated 2.5m and above, I will d

2007 year

TABLE 1600MM, WITH C AXIS, CHIP CONVEYOR AND TRANSFORMER OTHE ACCESORIES.

2003 year

chuck size 1250 mm 4 jaws, swing 1600mm, c axis , atc , siemens 840D controller, Turning height 1561mm

2003 year

TABLE DIAMETER 1250MM, SWING 1600MM, WORKING HEIGHT 1561MM , CROSS RAIL TRAVEL 900MM, HEAD 250X250MM, WITH C AXIS, MILLING DRIVER POWER 30KW,TOOL HOLDER SK50, 2 PALLETS, CONTROLLER SIEMENS 840D

year

 HTM-70/90 year 1991Distance Between Columns    9,000 mmMax Cutting Diameter & Max Swing    9,000 mmMax Cutting Diameter & Max Swing Set Back  &nbs

2001 year

NC VTL Gantry Type (With C-Axis)Make : Toshiba ShibauraModel : TMG-10750S(NC)Faceplate dia : 8000 mmSwing dia : 10,000 mmTurning height : 4350 mmMax. Job load : 250 TonTable speed : 0.16 ~ 16 RPMTable

2012 year

TABLE 1000MM, WITH C AXIS

2014 year

Table 5000Swing 8500Max. T/H 5,000Ram 2,500Max. Load 60TFanuc 31iARAA, EA, GAAOperator platform (elevator)Linear scale

2012 year

Table 5000Max. Swing 7000Max. Turning height 5000Load capacity 60,000 kgs (Thrust roller bearing)Table speed 1~50 rpmTable motor DC 121kwX axis -200~3,800Z axis 2,500mmCrossrail 250mm x 13 stepsRam si

2015 year

Table ¢6000 mmSwing ¢8000 mmMax. turning height 5000 mm Max. 120 tonTBle speed 1~40 rpm A.C 200 kw X stroke -200~+4300 mm Z stroke 2500 mmRam size 400×400 mmCrossrail 3250 mm(250 mm×13s

year

TABLE 3200MM, SWING 4000MM , FANUC SERIEC O-M

2015 year

CNC Vertical Turning Lathe Make : Toshiba Shibaura, JapanYear of manufacturing : 1989Year of retrofit : 2015CNC : Fanuc 0i-TD ControlTable dia : 5000 mmSwing dia : 6500 mmTurning height : 4000 mm

2011 year

YOU JI MACHINESL NOTECHNICAL SPECIFICATION1Type of machine:VERTICAL TURNING LATHE2Make:YOU JI3Chuck Dia:4000 mm4Max.Chuck rotating diameter capacity:4700 mm5Max.Chuck turning diameter capacity:4500 mm

2008 year

HNK NT-12/16F year 2008Table 1250Swing 1600Max. Turning height 750Ram stroke 600Table motor AC 37/45kwTable speed 360 rpmFanuc 18iTBATC 12T

1995 year

TABLE 5000MM, SWING 5300MM, LOAD TABLE 50 TONS, RAM SIZE 260X260MM TABLE MOTOR  DC 75KW,  TABLE RPM 1-30RPM,  MAGAZINE : JAPAN HOMMA, TH - 3000MM

2008 year

Table 1250Swing 1600Max. Turning height 750Ram stroke 600Table motor AC 37/45kwTable speed 360 rpmFanuc 18iTBATC 12T

2012 year

Table 1250Swing 1600Max. Turning height 900Ram stroke 900Table motor AC 37/45kwTable speed 350rpmFanuc 31iAATC 12T

2009 year

Table 2500 Swing 3000 Max. Turning height 2000 Z stoke 1200 Spindle motor AC 45/55kw Table load 20,000 kgs Table speed Max. 130 rpm Fanuc 18iTB ATC 12T Linear scale Splash guard Chip conv

2011 year

Table 1600 Swing 2000 Turning height 1556 Z stroke 960 AC 37/45kw Table speed Max. 250 rpm Fanuc i  ATC 12T 8 turning tools XZ linear scale Table enclosure  Chip conveyo

2012 year

Table 2000 Swing 2500 Turning height 1800 Z stroke 1000 Crossrail 250 x 3 steps AC 45/55kw Table speed 200 rpm Milling spindle AC 15/18.5kw Milling spindle speed 1500 rpm C-axis 0.001 deg.&

2003 year

Table 1250Swing 1600Max. Turning height 1000Z stroke 900AC 37/45kwATC 12FANUC CONTROL

2011 year

Table 2000 Swing 2500 Max. Turning height 1800 Ram stroke 900 Crossrail 250 x 3 steps AC 45/55kw Fanuc 18iTB ATC 12T Linear scale Splash guard

2009 year

1000MM CHUCK Fanuc 0i-TC Chuck dia. 40inch Max. Swing 1350mm Max. Turning dia. 1320mm Max. Turning height 950mm Table speed 630RPM Table motor 55 / 45Kw Turret 12 nos.  Milling spindle 3

year

table 4200 Swing 4500 Turning height 2200 Ram 1500

2010 year

Table 5000 Swing 5200 Turning height 3000 Ram stroke 1800 Table loading capacity 100T CONTROLLER : SENTROL2, MACHINE RETRO FITTED 2010

1995 year

Table 5000 Swing 5200 Turning height 3200 Ram stroke 1800 Table loading capacity 100T Siemens 840C

2013 year

chuck size :1600   Max diameter turning Capacity : Ø 1800mmMax turning height : 1300mm HighCONTROLLER : FANUC Oi-TD

1997 year

TABLE 2500 SWING 4000MM CONTROLLER FANUC TURNING HEIGHT

2008 year

TABLE SIZE 1250 MAX TURNING HEIGHT 900MM MAX TURNING DIA 1600MM C AXIS INDEX DEGREE 0.001 RAM SIZE 240X240MM MILLING SPINDLE 2000 RPM CONTROLLER FANUC 18I-TB MAX LOAD ON TABLE 600

2015 year

table ¢6000 mm Swing ¢8000 mm Max. turning height 5000 mm Max. 120 ton TBle speed 1~40 rpm  A.C 200 kw  X stroke -200~+4300 mm  Z stroke 2500 mm Ram size 400×400

1999 year

Chuck 3500. Turn diameter 7000 Height 2000. TABLE LOAD 40T.

2007 year

Table 2000Swing 2500Max. Turning height 1600Ram stroke 1000X stroke 1800Crossrail 1150Max. Load 10TSpindle motor AC 60/75kwSpindle speed Max. 200 rpmFanuc 18iTBATC 16

2001 year

TABLE DIAMETER 900MMMAX TURNING HEIGHT 580MMMAX SWING 1150MMLOAD ON TABLE 2 TCONTROLLER FANUC Oi-TD

2005 year

MAKE Hankook VTC-16/20EControlFanuc 18iTBYEAR2005Table 1600Swing 2000Max. TH 1400Table motor AC45/55kwTable speed Max.240 rpmZ-axis stroke 900Ram size 210 x 210 (BT.50)Mi

2014 year

 MACHINE SPECIFICATIONSQty: 1 machinesMAKE TOSHIBAModelTUE-23/33YEAR2014Table diameter2300mmMax swing3300mmMax cuting height1550mmMax load on table15000kgVertical travel of ram900mmTable spe

2011 year

Model VL-100CM Control FANUC Oi-TD YEAR 2011 X Axis travel Length  -100 to +800mm Z Axis travel Length 600mm

2010 year

TABLE DIA 4500MM MAX SWING DIA 5000MM MAX.CUTTING HEIGHT 3000MM MAX WORK PIECEC WEIGHT 50000 KG RPM 1-65 W AXIS CROSS RAIL UP DOWN - 2500MM X AXIS SADDLE L-R -2840MM Z AXIS RAM UP

2014 year

CNC VTL   Make  TOSHIBA MODEL TUE 23/33 Year of MFG 2014 Table Dia 2300 MM Maximum SWING 3300

1986 year

Make KOMATSU / JAPANMODELBTM 12 YYear of MFG1986/ RETRO FITTED 2013Table Dia1600MMMaximum Turning 1600MMMax Turning height1185MMNO.OF AXISX , Y, Z AND C AXISCONTROLLERFANUC 18I-MBSPINDLE TAP

2008 year

Table 1500Swing 1800Max. Turning height 1500Table speed Max. 250 rpmFanucATC 12

2008 year

 Max. Turning height 900mm (Distance from table top surface to the bottom of tool holder) Max.Turning dia. (Swing) Ø 1,600mm Max. Load on the table 6,000 kgB. Table Table Size

2004 year

Table 1600Swing 2000TH 1600Z stroke 900Fanuc 18iTATC 12

2005 year

TABLE - 3000MMSWING OVER - 3500MMMAX TH- 2650MMRAM SIZE 210 X 210MMFANUC 18I-T

2010 year

Table 4000Swing 6700Max. TH 2600X stroke 2450Z stroke 1500Crossrail elevation 2000Table horizontal stroke 1200Table speed Max. 80 rpmMilling spindle speed 1500 rpmFanuc 31iA

2012 year

Table 1600Swing 2000Turning height 1750Ram stroke 1000Ram size 240 x 240AC 37/45kwTable speed Max. 250 rpmMilling spindle Max. 2000rpmCrossrail 250 x 3 stepsATC 16TRAAFanuc 32iA

2013 year

MAX SWING 3400 MM MAX FACING CAPACITY 3400 MMRAPIND TRAVERSE X - 20000 MMPMZ AXIS TRAVEL 1750MMRAM SIZE 250X250MMTWO SPEED GEAR BOX, SPINDLE SPEED 4000 RPMC AXISTABLE SPEED 150 RPM , AND LOAD CAP

2009 year

Turn millTable 1000Swing 1250Max. Turning height 800Ram stroke 800C axis 0.001 deg. Max table speed 450 rpmFanuc 21iATC 16(8T + 8M)

2007 year

Table 1400mmSwing 1600mmTurning height 900mmX stroke 1600mmZ stroke 900mmCrossrail 700mmSpindle speed Max. 320 rpmSpindle motor AC 37/45kwMilling spindle speed Max. 3,000 rpmMilling spindle motor AC 1

2009 year

Table 1600Swing 2000Turning height 1400Ram stroke 900Crossrail 700Table motor AC 37/45kwTable speed Max. 280 rpmFanuc 21iATC 12TChip conveyor Splash guard

2006 year

MAX TURNING DIAMETER - 2000 MMMAX SWING - 2000 MMMINIMUM INTERNAL DIAMETER TABLE LOAD 10 TONS

2000 year

Table 1250(HYD chuck 3 Jaw)Max. Turning dia. 1600Max. Turning height 1000Ram stroke 900Ram size 200x200FANUC 18TAC 37/45kW320rpmATC12

2009 year

Table 2500Swing 3500Max. Turning height 2000Z stoke 1200Spindle motor AC 45/55kwTable load 20,000 kgsTable speed Max. 130 rpmFanuc 18iTBATC 12TLinear scaleSplash guardChip conveyor

2008 year

ATC - 8 TOOLSBT 50TABLE - 1200MMCONTROLLER : FANUC Oi TO

2013 year

Doosan VTS-1620 year 2013Table 1600Swing 2000Turning height 1556Z stroke 960AC 37/45kwTable speed Max. 250 rpmFanuc i ATC 12T8 turning toolsXZ linear scaleTable enclosure Chip conveyo

2009 year

Model YV-1600 ATC year 2009Table 1600Max. Swing 2000Max. Turning height 1200Ram stroke 900Crossrail 750Table speed Max. 250 rpmAC 37/45kwFanuc 0iTDATC 12TTool length measurement Linear scale

2003 year

Froreip CNC VTLChuck : 1400mmSwing : 1700mmHeight : 1350mmFanuc 16iT ControlOriginal cnc vtl With ATC

2015 year

Table Dia3500MMMaximum Turning 4500MMMax Turning height2500MMCONTROLLERFANUC 31iBSPINDLE TAPERBT50ATC12 TOOLSCHIP CONVEYORYES

2008 year

Make O-M MODELNeo-16Year of MFG2008Table Dia1600 mmMaximum Turning 2000 mmMax swing2000 mmMax Turning height1500 mmMax mass of work piece8000 kgMax height from table top to gauge line17

2014 year

Make SAMSUNG , KOREAMODELKTC 12/16Year of MFG2014Table Dia1250MMMaximum Turning 1600MMMax Turning height1300MMCONTROLLERFANUC 32i- Model ASPINDLE TAPERBT50ATC12 TOOLS

2002 year

Make O-M MODELTMS2-30/55NYear of MFG2002Table Dia3000 mmMaximum Turning 5500 mmMax swing5600 mmMax Turning height2600 mmMax mass of wrok piece30000 kgTable rpm 0.8-80 rpmVertical t

1970 year

Diameter of Table2000 mmMaximum swing2230 mmMaximum turning height1320 mmMaximum speed2 - 100 RPMMaximum table sload10 TonsTraverse of ram1200 mmWeight of machine43 Ton

2012 year

Table Dia - 1000 mm, Max Turning Dia- 1100 mm, Max Swing Dia 1200 mm, Max Weight of Workpiece - 3,500 KgsTravel - Z Axis - 600 mm, X Axis - L100 + R800, Tool Size - 25 x 25 , 32 x 32 mmCNC Controller

2010 year

BT 50ATC - 12 NOSTABLE SIZE - 2000 MMVERY GOOD WORKING CONDITION

2014 year

Track gaugeΦ3500mmΦ137.8inchWheel diameterΦ4000mmΦ157.5inchShaft length3000mm〔3400mm〕118.1inch（133.9inch）Max. weight20000kg

2004 year

X  travel1320 mmZ travel800 mmMax turning height800mmSwing over bed150mmTable Diameter1100mmMax work rpm600 rpmATC 12 ToolsSpindle taperBT50Controller Fanuc 18--TBCoolant TankYestool/wo

2016 year

Controller: FANUC 0i-TFTable dia.: 1600mmMax. swing: 2000mmMax. turning dia.: 1800mmMax. turning height: 1200mmX axis travel (left-right): -3593~+1103mm (incl. ATC travel)Z axis travel (up-down): 900m

2007 year

FANUC OI-TCBT50ATC - 12 TOOLS

2006 year

Controller: FANUC 0i-TCMax. swing dia.: 1,600mmTable dia.: 1,250mmMax. table load: 5,000kgsMax. table speed: 350rpmMax. cutting height: 1,200mmMax. cutting dia.: 1,350mmX/Z axis travel: 930/850mmVerti

2012 year

TABLE 1600MMSPINDLE THRO COOLANTGOOD RUNNING CONDITIONTOOL HOLDER BT50

2007 year

Face palte DIa : 4770mm Max. Dia of workpiece : 5200mm MAx. work piece height : 3000mm Max weight of work piece : 60 tons Table feeds ; 0.331-32.8 rpm Feeds 0.25-11.2 mm/min Feed fas

2006 year

Controller: FANUC 0i-TCMax. swing dia.: 1,600mmTable dia.: 1,250mmMax. table load: 5,000kgsMax. table speed: 350rpmMax. cutting height: 1,200mmMax. cutting dia.: 1,350mmX/Z axis travel: 930/850mmVerti

2012 year

ax. swing dia.    1200 mm (47.24")Max. turning dia.    1200 mm (47.24")Max. turning height    800 mm (31.49")Table dia    1000 mm (39.37")X-

2009 year

TABLE 1.6M

2008 year

2018 year

Table - 2000 mmYear of Mfg - 2018ATC - 60 tools

2011 year

Make / Model Yu Shine / VL - 1100 HRYear 2011Max Swing DiaDia 1250 mmMax Turning diaDia 1100mmMax. Turning Height1000 mmChuck size1000 mmSpindle noseBT 50Turret10 TX axis travel800mmZ axis t
