Max. Turning height 900mm
 (Distance from table top surface to the bottom of tool holder)
 Max.Turning dia. (Swing) Ø 1,600mm
 Max. Load on the table 6,000 kg
B. Table
 Table Size Ø 1,250mm
 Table speed 1~350 rpm
 C. C-axis
 Index degree 0.001°
 Max. Speed Max.3 rpm
D. Ram head
 Ram size 240 x 240mm
 Milling spindle speed 2,000rpm
Spindle taper ISO 50.
 E. Travels
 X-axis (Saddle cross) -1,480 ~ +1,480mm
 Z-axis (Ram vertical) 900mm
 W-axis (Crossrail vertical) Fixed type
F. Motors
 Table motor AC 37/45 kw
 Milling spindle motor AC 15/18.5kw
Servo motor(X,Z,C) AC 4kw
 F. CNC system
 Fanuc 18i-TB
 Display 10.4” TFT Display

Optional Machine Features
Automatic Tool Changer system 12 Tools (6T + 6M)
