5 AXIS MACHINE DMG MORI NT 4250DCG/ 1500S
MACHINE MORE INFORMATION
| Machine | 5 AXIS MACHINE |
| Brand | DMG MORI |
| Model | NT 4250DCG/ 1500S |
| Year | 2015 |
| Specification | §Model : NT 4250DCG/ 1500S §MFG Year: 2015 §Controller : Fanuc-31iA5 §Max. Swing 730 mm §Center distance : 1862mm §Chuck : 12 inch (main & sub) §Swing on cross slide : 730mm §Max work size : Dia 660 mm / Length 1542mm §Bar workability : 80/80mm (sub spindle) §Travel XYZ : 750 / 210 / 1550+100mm (ATC) §B axis Index 120 deg §Spindle : 4000 rpm , 1/10000 index (main&sub) §Milling head : 12000rpm, Capto C6, ATC 40 stations |
