Maximum workpiece diameter : 730 mm
Maximum workpiece height : 1000 mm
X-Axis stroke : 1100 mm
Y-Axis stroke : 800 mm
Z-Axis stroke : 900 mm
B-Axis center to pallet center (X-axis home) : 1020 mm
B-Axis center to pallet center (X-axis minus end stroke) : -80 mm
Spindel nose to pallet center (B=90°, X-axis is home) : 771 mm
Minimum/Maximum B-Axis center to pallet top : 100/1000 mm
Minimum/Maximum spindle nose to pallet top (B=0°) : -149/751 mm
Maximum pallet load : 800 kg
Milling spindle:
Spindle nose : capto C6
Minimum/Maximum Rotational speed : 35-12000 rpm
Number of speed shifts : 2
