Table Size
2,500 x 5,000 mm
X Axis 5,200 mm
Y Axis 3,500 mm
Z Axis 800 mm
W Axis 1,300 mm
Spindle Speed
20 - 8,000 rpm
Spindle Taper
7/24 Taper No 50
Spindle Motor
30 kW
Distance Table Surface to Spindle Nose
1,850 mm
Distance Between Columns
3,250mm
Fanuc 31i MB
50 Position ATC
Chip Conveyor
MP Scale Feedback for All Axes – X,Y,Z,W
Coolant Through Spindle
Right Angle Head
Attachment Storage Rack
