CNC HMC CHEAP PRICE NEED QUICK CLEARANCE MAKINO A55

Machine

CNC HMC CHEAP PRICE NEED QUICK CLEARANCE

Brand

MAKINO

Model

A55

Year

1999

Specification

MAKE	Makino
Control	Professional
Model	A55
YEAR	1999
X axis	560mm
Y axis	500mm
Z axis	500mm
Distance from table surface to spindle center	90-640mm
Distance from table center to spindle nose	150-710mm
Table (pallet) working surface	400x400mm
Pallet loading capacity	400kg
Height up to pallet surface	1100mm
Table indexing time	3 sec per 90degree
Spindle speed range	120-12000rpm
Spindle beaing inner diameter	85mm
Spindle drive motor	AC 22kW(15 min rating)/18.5kW(continuous rating)
Spindle starting characteristics	1.7sec (at 12000rpm)/ 0.5sec (at 6000rpm)
Rapid traverse rate	24000mm/min
Feedrate	1-8000mm/min
Took shank	40T
Max tool length	300mm
Max tool weight	8kg
Electrical power supply	AC 200/200 V+/- 10%
Machine height	2820mm
Machine weight	8400kg
