Center length 3000mm
Max. Swing 820mm
Spindle speed 3300 rpm
B axis 240 deg.
Milling spindle 10000 rpm
XYZW 870/500/3122/2463mm
ATC 40

controller :mazatrol matrix 2

Chuck size 21”
Max. Swing 820mm
Max. Cuttin length 3,053mm
ATC 80(CAPTO)
Spindle speed 3300 rpm
Spindle motor AC 30kw
Milling spindle AC 37kw, 10,000 rpm
XYZ 870/500/3122
B axis -30 ~ +210 deg.

Options
Tool eye for 24” chuck
Laser mill tool measurement
Scale feedback (X, Y-axis)
Hobbing function
Coolant temperature control system
Coolant thru spindle 70bar
HYD steady rest SLU-X 5.1
Single/1NC base
Chip conveyor
B) Milling-Spindle simultaneous tapping
F) Simultaneous 5-axis EIA/ISO function
F) Tool tip point control / Simultaneous 5-axis
F) Tool radius compensation 5 axis
EIA dynamic compensation 2
B)G00 constant control
D)MAZACC-30 High speed compensating package
B) Rotary axis compensation
D) High smoothing control
B) Circular interpolation and polar coordin
