X-axis travel mm 5050
Y-axis travel mm 2100
Z-axis travel mm /1070(op)
Spindle end to table mm 225-1005-
225-1295(op)
Spindle center to machine column mm 430
Distance between double columns mm 2300
Workbench area mm 5150x2040
T-slot (X direction) mm 22x9x200
Maximum load capacity of workbench kg 12000
Power(30 mis/cont.) kw 22/26
Spindle (gear type) speed rpm 6000
DDS(long nose end) rpm 10000(op)
Spindle taper ISO50
Cutting speed X/Y/Z mm/min 5000
Rapid traverse speed X/Y/Z mm/min X,Y=12000
Z=15000
