Largest workpiece diameter: 1050 mm
Normal module range:6 mm-23 mm
Reference cone angle setting range: -5°-+90°
Axis displacement above center / below center: ± 150 mm/± 100 mm
Spiral angle to be ground (in the middle of the tooth): 0°-60°
Diameter of the workpiece spindle hole: 270 mm
Grinding wheel diameter: 190 mm-559 mm (7.5 in-22 in)
Highest grinding spindle speed: 3000 rpm

Highest workpiece spindle speed: Continuous operation 12 rpm Divide and roll 20 rpm

Axis data and drive data:-

Grinding spindle 1/grinding spindle 2 (A1 axis/A5 axis)
Main spindle motor: Siemens 1PH4167-4NF262-Z
Torque: 293 Nm
Motor speed: 1500 rpm-6500 rpm
Weight: 210 kg
Output: 46 kW

Eccentric drive for grinding spindle 1/eccentric drive for grinding spindle 2
(A2 axis/A6 axis)

Servo motor: Siemens 1FT6086-1AH71-3EH1
Torque: 27 Nm
Motor speed: 4500 rpm
Maximum Weight: 25.5 kg
